Description
Authorized channel sourcing — Every INA NKS65-XL needle roller bearing we supply ships with distributor-chain documentation and batch-level traceability back to the Schaeffler production lot.
Technical Specifications
| Parameter | Value |
|---|---|
| Designation | INA NKS65-XL |
| Bearing Type | Needle Roller Bearing (Without Outer Ring, Without Inner Ring) |
| Bore Diameter (Fw) | 65 mm |
| Outside Diameter (D) | 85 mm |
| Width (B) | 28 mm |
| Weight | 0.1 kg |
| Seal or Shield Type | Open |
| Number of Rows | Single Row |
| Material | Bearing Steel |
| Load Direction | Radial |
| Cage Material | Pressed Steel (standard for INA NK series) |
| Arrangement | Without Outer Ring, Without Inner Ring |
| Origin | Manufacturer’s production facilities (Schaeffler network) |
The XL suffix designation in this context has not been fully verified against the current Schaeffler product catalog; confirm suffix meaning with supplier documentation before final application approval.
Application Suitability
| Industry | Typical Applications |
|---|---|
| Industrial Machinery | Conveyor guide rollers, transmission shaft support journals |
| Material Handling | Forklift mast roller tracks, crane sheave pivot points |
| Automotive and Heavy Vehicle Repair | Gearbox layshaft needle positions, steering column universal joints |
| Agricultural Machinery | Harvester rotor shafts, PTO driveline support bearings |
| General MRO | Replacement needle bearings on OEM equipment where shaft serves as inner raceway |
